Series DFS2

Chưa có lượt đánh giá nào - Chưa có câu hỏi nào - 788

Yêu cầu báo giá

Tổng quan về sản phẩm

Thông số kỹ thuật:

Sensing Element: Vapor-filled capillary.
Operating Temperature: 14°F to 54°F (-10°C to 12°C).
Storage Temperature: 14°F to 158°F (-10°C to 70°C).
Capillary Overload Temperature: 392°F (200°C), maximum 60 minutes.
Humidity Limit: 0 to 95% RH, non-condensing.
Enclosure: Galvanized steel base, ABS cover.
Enclosure Rating: NEMA 1 (IP40).
Capillary Material: Copper.
Cable Entry: (1) M20 compression fitting.
Reset Action: Available in automatic or manual reset options.
Low-level Setpoint: Factory Set: 39°F (4°C), and safety lock secured; Adjustment via screwdriver slot.
Wire Connection: Terminal with wire-retaining screws.
Wire Size: Max. 14 AWG.
Electrical Rating: 24 to 250 VAC, 15 (8) A.
Electrical Connections: Two each NO/NC/Common.
Deadband: 1.8°F (fixed).
Weight: 1.6 lb (0.7 kg).
Agency Approvals: CE.

Ordering:

Model	Description
DFS2-DA10	Low limit temperature control, 10 ft capillary with automatic reset
DFS2-DA20	Low limit temperature control, 20 ft capillary with automatic reset
DFS2-DM10	Low limit temperature control, 10 ft capillary with manual reset
DFS2-DM20	Low limit temperature control, 20 ft capillary with manual reset
