Thông số kỹ thuật
- Service: Compatible liquids and gases.
- Wetted Materials: 316L SS.
- Housing: Polycarbonate.
- Accuracy: ±1% of FS including linearity, hysteresis, and repeatability (indicator and transmitter).
- Stability: < ±2% of FS per year.
- Pressure Limits: 1.5 x range.
- Temperature Limits: Ambient: 20 to 140°F (-6.6 to 60°C); Process: 0 to 176°F (-18 to 80°C).
- Compensated Temperature Limits: 32 to 122°F (0 to 50°C).
- Thermal Effect: ±0.05% of F.S./°F.
- Display: 4-digit backlit LCD (Digits: 0.60"H x 0.33"W).
- Power Requirements: 12 to 30 VDC/AC.
- Power Consumption: 2.5 watts.
- Electrical Connections: Removable terminal blocks with two 1/2" female NPT conduit connections.
- Enclosure Rating: Meets NEMA 4X (IP65).
- Warm Up Time: <10 seconds.
- Mounting Orientation: Any position.
- Weight: 1.18 lbs (535 g).
- Agency Approvals: CE, UL.
SWITCH SPECIFICATIONS:
- Switch Type: 2 SPDT relays.
- Electrical Rating: 5 A @ 120/240VAC, 1 A @ 30 VDC.
- Repeatability: ±1% of FS (switching only).
- Set Points: Adjustable 0-100% of FS.
- Switch Indication: External LED for each relay on the front panel.
- Switch Reset: Manual or Automatic.
TRANSMITTER SPECIFICATIONS:
- Output Signal: 4-20 mA, 1-6 VDC, 1-5 VDC, 0-5 VDC, or 0-10 VDC (direct or reverse output selection).
- Minimum Excitation: 14 VDC.
- Zero and Span Adjustments: Menu scalable within the range.
