Mounting Orientation: F6-SS: vertical ±20°, F6-MHS/HPS: horizontal with index arrow pointing up or down.
Specific Gravity: F6-SS: 0.65, F6-MHS: 0.85, F6-HPS-11, 21, 31: 0.6.
Weight: F6-HPS-11, 21: 1.23 oz (38 g), F6-MHS-31: 1.41 oz (40 g), F6-MHS: 3.35 oz (95 g), F6-SS: 1.59 oz (45 g).
Agency Approvals: CE.
SERIES F7
Electrical Rating (Maximum): F7-SB, -SS2 AC: 25 VA, 1.0A, 200 V DC: 10 W, 1.0 A, 200 V F7-PP, -BT, -HSS, -MHS AC: 25 VA, 1.0 A, 200 V DC: 10 W, 1.0 A, 200 V F7-HPS-1, -2 AC: 25 VA, 1.0 A, 200 V DC: 10 W, 1.0 A, 200 V (F7-HSS is rated explosion-proof for Class I, Groups A, B, C, D; Class II, Groups E, F, G; Class III).
Mounting Connection: 1/8" NPTM (all vertical mount), 1/2" NPTM (F7-HPS-2, F7-HSS), M16 x 2 (F7-HPS-1), 1/2" x 13 thread (F7-MHS).
Wire Leads: 22 AWG x 18" (46 cm), vertical mount models; 22 AWG x 39" (1 m), models F7-HPS-1, -2; 22 AWG x 24" (61 cm), models F7-HSS, -MHS.
