Wetted Materials: Body and fitting: Brass or 316 SS; Fitting O-ring: FKM standard, silicone or Buna-N optional; Impeller: 316 SS; Shaft: tungsten carbide standard or 316 SS optional; Bearing: PTFE standard.
Process Connection: 1-1/2" NPT male standard, 2" NPT male optional.
Output:
> Pulse: NPN open collector with square wave output, rated 60 V @ 50 mA maximum.
Frequency: 3.2 to 200 Hz. Pulse Width: 2.5 msec ±25%.
4 to 20 mA: 4 mA is 0 ft/s, 20 mA is 25 ft/s.
Power Requirement: 10 to 35 VDC.
Power Consumption: 40 mA (max).
Electrical Connection: 22 AWG shielded UL type PTLC rated 105°C, 20' (6.1 m) long with cable gland. Can be extended up to 2000' (609 m) with similar cable. Optional UL listed burial rated cable.
