2.5% FS Accuracy, 316 SS or Brass Wetted Parts, Dual PSI/Bar x100 kPa Scales
1.5" Industrial Pressure Gage is used in applications that need to be resistant to corrosion. Economical choice where corrosion and vibration are a concern.
Features
-
Stainless steel housing to resist ambient corrosion for longer service life in harsh environments
-
Good accuracy gage for value-sensitive applications requiring more precise measurement and where vibration is a concern
-
Back or bottom mounting and compact size provides for mounting with dimensional limitations
Product Applications
-
Vacuums in pneumatic conveying lines
-
Positive pressure in compressed air headers
-
Corrosive ambient environments
Specifications
-
Service: Compatible gases and liquids.
-
Wetted Materials: Brass connector, bronze tube.
-
Housing: 304 SS.
-
Lens: Polycarbonate.
-
Accuracy: ±2.5% FS.
-
Pressure Limit: FS range.
-
Temperature Limits: -4 to 140°F (-20 to 60°C).
-
Size: 1.5" (40 mm).
-
Process Connections: 1/8" NPT.
-
Weight: 2.2 oz (63 g) bottom, 2.3 oz (65 g) back.
