Series TTE

Chưa có lượt đánh giá nào - Chưa có câu hỏi nào - 696

Thương hiệu:
Dwyer
Sản xuất tại:
Mỹ
Mã HH:
Đơn vị tính:
Cái

Yêu cầu báo giá

Tổng quan về sản phẩm

Thông số kỹ thuật:

Temperature Sensor: Pt1000, 0.00385 DIN.
Output Temperature Ranges: User selectable - any range between -30 to 250°F with a minimum span of 40°F.
Temperature Limits: Ambient: -4 to 158°F (-20 to 70°C); Process: -30 to 250°F (-34.4 to 120°C).
Accuracy: Transmitter: ±0.1% FS; Probe: ±0.3% FS.
Thermal Drift Effects: ±0.02%/°C max.
Response Time: 250 ms.
Wetted Materials: 316 SS.
Process Connection: 1/2" male NPT or 1/2 male BSPT.
Conduit Connection: 1/2" female NPT or M20.
Probe Length: 2" to 18" (depending on model).
Pressure Limits: 2000 psi (137.9 bar).
Power Requirements: 10 to 35 VDC.
Output Signal: 4 to 20 mA (two wire loop powered).
Optional Display: 2 lines X 8 character LCD.
Enclosure Rating: Weatherproof and Explosion-proof. Listed with FM for Class I, Division 1, Groups B, C and D, and dust ignition-proof for Class II, Division 1, Groups E, F and G and Class III atmospheres.
- ATEX Certified: CE 0518 II 2 G Ex db IIC, CE (Ex) II 1 D Ex ta IIIC T111°C Da, T6 Process Temp =80°C, Temperature Class T5 Process Temp =95°C, Temperature Class T4 Process Temp =120°C as defined on nameplate. EU-type Cerificate No.: EMT17ATEX0021 X. (Pending) ATEX Standards: EN 60079-0:2012+A11:2013; EN 60079-1:2015; EN 60079- 31:2014. (Pending)
- IECEx Certified: For Ex db IIC T6 Gb, Ex ta IIIC T111°C Da, Process Temp =80°C, Temperature Class T5 Process Temp =95°C, Temperature Class T4 Process Temp =120°C as defined on nameplate. (Pending)
- IECEx Certificate of Conformity: Element IECEx EMT 17.0007X; IECEx Standards: IEC 60079-0:2011 (Edition 6); IEC 60079-2014 (Edition 7); IEC 60079-31:2013 (Edition 2). (Pending)
Weight: 2 lb 8 oz (1134 g).
Agency Approvals: FM, CE, ATEX/IECEx.

Ordering:

Model	Description
TTE-104-W	Explosion-proof RTD temperature transmitter, 4" probe.
TTE-104-W-LCD	Explosion-proof RTD temperature transmitter, 4" probe, with LCD display.
TTE-106-W	Explosion-proof RTD temperature transmitter, 6" probe.
TTE-106-W-LCD	Explosion-proof RTD temperature transmitter, 6" probe, with LCD display.
TTE-109-W	Explosion-proof RTD temperature transmitter, 9" probe.
TTE-109-W-LCD	Explosion-proof RTD temperature transmitter, 9" probe, with LCD display.
TTE-112-W	Explosion-proof RTD temperature transmitter, 12" probe.
TTE-112-W-LCD	Explosion-proof RTD temperature transmitter, 12" probe, with LCD display.
TTE-115-W	Explosion-proof RTD temperature transmitter, 15" probe.
TTE-115-W-LCD	Explosion-proof RTD temperature transmitter, 15" probe, with LCD display.
TTE-118-W	Explosion-proof RTD temperature transmitter, 18" probe.
TTE-118-W-LCD	Explosion-proof RTD temperature transmitter, 18" probe, with LCD display.
